| Chipset | Intel H510 |
| Socket | Intel LGA 1200 |
| Kích thước Main | M-ATX |
| Hỗ trợ CPU | Intel Socket LGA1200 cho bộ vi xử lý Intel Core thế hệ 11 & Intel Core thế hệ 10, bộ vi xử lý Pentium Gold và Celeron |
| Khe cắm RAM | 2 khe ram |
| Loại RAM | DDR4 |
| Bus RAM hỗ trợ | 2 x DIMM, Max. 64GB, DDR4 3200(OC)/2933/2800/2666/2400/2133 MHz Non-ECC. Max 64Gb |
| Chi tiết Vga | 1 x HDMI port, supporting a maximum resolution of 4096x2160@30 Hz Support for HDMI 1.4 version and HDCP 2.3. 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz The D-Sub port is only available with the 10th Generation processors. |
| Kết nối mạng | 1Gb Ethernet |
| Thông số (Lan/Wireless) | Realtek RTL8111H, 1 x Gigabit LAN |
| Khe cắm trong | 1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 SATA and PCIe 3.0 x4/x2 SSD support) 4 x SATA 6Gb/s connectors Refer to 1-7 Internal Connectors,for the installation notices for the M.2 and SATA connectors. |
| Khe cắm mở rộng | 1 x PCI Express x16 slot, running at x16 (PCIEX16) For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot. (The PCIEX16 slot conforms to PCI Express 4.0 standard.) Supported by 11th Generation processors only. 1 x PCI Express x1 slot (PCIEX1_1) |
| Cổng giao tiếp ngoài | 1 x PS/2 keyboard/mouse port 1 x D-Sub port 1 x HDMI port 2 x USB 3.2 Gen 1 ports 4 x USB 2.0/1.1 ports 1 x RJ-45 port 3 x audio jacks |
| Âm thanh | Realtek ALC887 8-kênh CODEC Âm thanh HD |
